Description
Packing material:
LDPE shrink film. Both transparent and printed shrink film can be used.
- Single film packing is overlapped at the bottom of the products, there are no heat seals on the packages.
- Multi-Axis of PC base programming control by color touch screen operation. Within specified range (LxWxH) for different products is completely simple for size-change on the screen.
- Each action & workstation of machines can be displaved on the screen for view.
- Film is delivered by Servo motor, so the film length is easily controlled. Sucking conveyor is equipped.
- Two film cradles of single-spindle air pressure can be exchanged. Each set can bear 60~90kgs of film roll.
- Film-rolling mechanism is controlled by Servo motor, the packing in different heights can proceed at any time. Automatic trip device for breakdown and lip type conveyor are also equipped.
- Can match the interlocking control system of before/after production lines.
- Body is made of standard steel #SS41 with powder painted surface. Inner oven is made of SUS#304.
- Electric heating stainless steel tube is equipped with fin & installed with ceramic adapter wires at two ends, so temperature can be adjusted. ABM Mineral Wood board covers heat-reserving layer.
- Twin circulation fans are to ensure even heat distribution inside shrink oven. Heat wind direction is adjustable. Heat wind direction is adjustable.
- Machine’s structure is melted & formed with square SS41 steel pipes with powder painted surface.
| Specification | Overlapping Mach. | Shrink Tunnel |
| Packing capacity | 20~30 packs/min | 5~25 m/min |
| Effective packing size (L x W x H) | 320~420 x 200~400 x 140~330 mm | 420 x 400 x 350 mm |
| Film applied | PE transparent or printed film | |
| Power | 220/380V, 3 phase, 50/60Hz | |
| HP | 6 HP | 42 HP |
| Electric heating | – | 32kW |
| Air pressure | 5~6 kgf/cm2, 100nl/min | – |
| Machine dimension (L x W x H) | 2,800 x 1,190 x 1,450 mm | 2,600 x 1,330 x 1,810 mm |
| Machine weight | 750 kgs | 800 kgs |
